Dental 3D Printing Workflow & Training Pack
Dental 3D Printing Workflow & Training Pack - is backordered and will ship as soon as it is back in stock.
FAQ
FAQ
Livraison et expédition
Livraison et expédition
Mode d'expédition :
- France Point Relais
- Livraison Province lendemain avant 13h
- Livraison Province lendemain avant 18h
- Paris livraison en cabinet exclusivement
- Livraison locale - Île-de-France ( Petite couronne )
Retrait sur place :
Évitez les frais de livraison pour vos petites commandes en venant les récupérer directement dans nos locaux, au 10 rue Parmentier, 93100 Montreuil.
Description
Description
The Rayshape dental 3D printing chain pack is a complete solution for dental offices and laboratories wishing to integrate a reliable digital workflow, from printing to clinical use.
It combines a choice of Rayshape 3D dental printer, an ultrasonic cleaner for post-processing, a curing unit, and guided implantology training to produce printed devices with autonomy, precision, and reproducibility.
Equipment and services included in the pack
Edge Mini 3D dental printer - Rayshape: a compact, precise, and fully automated printer, suitable for daily dental applications. It allows quick production of models, restorations, surgical guides, and aligners directly in the office.
Edge E2 3D dental printer - Rayshape: an LCD printer designed for offices and laboratories seeking higher production capacity. It enables entry into a fast, precise digital dental workflow suitable for over 20 clinical indications.
ShapeWash 020S ultrasonic cleaner - Rayshape: essential for post-processing, it removes uncured resin residues evenly. Its 3.2 L tank is suitable for 3D printed dental parts and helps improve surface quality before final curing.
ShapeCure D curing unit - Rayshape: designed to harden resin parts from 3D printing, it ensures reliable and uniform final curing. Its simplified operation helps streamline the workflow in the office or laboratory.
Training in digital dentistry and guided implantology: dedicated support to master the digital workflow, from planning to 3D printing, to fully utilize the complete chain with a structured clinical approach.
Key benefits
- Complete chain: the pack combines printing, cleaning, curing, and training to secure every step of the digital workflow.
- Capacity choice: the Edge Mini is suitable for compact integration in the office, while the Edge E2 meets higher production needs.
- Controlled post-processing: the ShapeWash 020S removes resin residues and the ShapeCure D finalizes the mechanical properties of the printed parts.
- Multiple applications: both variants allow producing surgical guides, models, splints, provisionals, and prosthetic devices depending on the resins used.
- Clinical support: included training helps the team connect digital planning, 3D printing, post-processing, and clinical use.
Indications
- Guided implantology: producing surgical guides to transfer digital planning to the operating room.
- Provisional prosthesis: printing temporary crowns, provisional restorations, and aesthetic validation devices.
- Orthodontics: manufacturing models, splints, clear aligners, and indirect bonding trays.
- Digital practice workflow: internalizing production to reduce lead times, secure clinical steps, and improve appointment management.
Technical specifications
| Compared item | Edge Mini - Rayshape | Edge E2 - Rayshape |
|---|---|---|
| Technology | LCD | LCD |
| Print volume | 60 × 60 × 100 mm / 130 × 80 × 100 mm | 192 × 120 × 190 mm |
| XY resolution | 35 μm | 50 μm |
| Layer thickness | 0.05 to 0.20 mm | 0.05 to 0.10 mm |
| Printing speed | Depending on indication and resin used | Up to 40 mm per hour |
| Dimensions | 300 × 280 × 427 mm | 390 × 420 × 535 mm |
| Net weight | 12 kg | 26 kg |
| Applications | Models, surgical guides, provisional restorations, aligners, splints | Surgical guides, splints, gingiva, dental prosthesis, models, clear aligners, provisional restorations, indirect bonding trays |
| Cleaning included | ShapeWash 020S - 3.2 L tank for post-processing 3D printed parts | |
| Polymerization included | ShapeCure D - polymerization unit for resin-printed parts | |
| Training included | Training in digital dentistry and guided implantology | |
| Warranty | 1 year | 1 year |
Service & support oofti
oofti.fr supports dental surgeons and laboratories in integrating digital technologies into the practice, with a selection of Rayshape equipment, a coherent post-processing chain, and associated training. The goal is to enable autonomous, structured, and reproducible use of dental 3D printing to serve clinical precision.
